Raymond Mill

Raymond Mill Production Line is designed by our institute through many years hard work and study of powder processing machinery, which creates a new era of high-efficiency and low-consumption grinding mill.

CONTACT NOW

Product Detail

Product Tags

Application

This machine is suitable for producing minerals powder, which is widely used in the fields of mining, metallurgy, chemical, construction and mining industry. It can be used for grinding barite, limestone, porcelain, slag and other materials that Moh’s hardness is below 9.3, humidity is in 8%, and non- flammable non- explosive minerals. The final product size can be adjusted as required in the range of 80~400 meshes. And the special coarse powder device (30- 80mesh) is also available.

Advantages

1. Adopted three - dimensional structure with small footprint, it is an independent production system from bulk to finished powder.

2. High capacity: This model is improved on the basis of YGM-type grinder with system upgrade, more reasonable configuration and higher capacity.

3. Wear - resistant and more stable operation. The machine has high wear-resistant performance,

because important parts are made of high-quality steel, meanwhile, wearing parts are made of high-performance wear-resistant materials. And the transmission device adopts sealed gear box and pulley, stable transmission and reliable operation.

4. Large conveying capacity: blower adopts high-pressure centrifugal fan, which make air volume and pressure increase that greatly improving the pneumatic conveying capacity.

5. High classification accuracy: the classifier is cage type classifier, and the granularity of the finished product is adjusted arbitrarily within 80-400 meshes.

Main Technical Data

Main Technical Data of

Model	Ring Diameter (mm)	*Rollers DiameterH (mm)**	Speed of Main Mill (r/min)	Max. Feeding Size (mm)	Output Size (mesh)	Capacity (t/h)	External Dimension (mm)
YGM1100	φ1100	φ320×170	132	≤25	80- 400	0.5- 6.5	735059007900
YGM1400	φ1400	φ430×210	106	≤30	80- 400	2- 13.8	800085509700
YGM1500	φ1500	φ460×230	105	≤30	80- 400	2.9- 17.5	9700850010200
YGM1750	φ1750	φ520×270	92	≤30	80- 425	44706	92301011610510
YGM2000	φ2000	φ600×300	78	≤35	80- 425	6.5- 32	93681150011000
YGM2200	φ2200	φ630×320	72	≤35	80- 425	8.4- 40	104651137211500

Power Specification

Model	Mill Power (kW)	Power of Air Blower (kW)	Power of Classifier (kW)	Model of Pulse Dust Collector	Dust Collector Blower+ Air Compressor (kW)	Power of Frequency feeder (kW)
YGM1100	37	30- 37	5.5- 11	DMC36	3+4	0.15
YGM1400	75- 90	75- 90	18.5- 22	DMC36	3+4	3
YGM1500	90- 110	110- 132	22- 30	DMC48	3+4	4
YGM1750	132- 160	160- 200	30- 37	DMC64	5.5+5.5	5.5
YGM2000	185- 200	200- 220	37- 45	DMC96	7.5+7.5	5.5
YGM2200	220- 250	220- 250	45- 55	DMC96	7.5+7.5	5.5
